Felder saw-spindle moulder

This used Felder saw-spindle moulder combines a circular saw with a sliding table and a spindle moulder with a tilting spindle on a single frame. It is intended for joinery and furniture workshops working with both solid wood and panels: panel sizing, ripping and crosscutting, tilted cuts up to 45°, and profiling, rebating and grooving with the spindle moulder. It processes solid softwood and hardwood and wood-based composite panels. The circular saw takes a Ø 315 mm blade, tilting manually 0–45°, with a maximum cutting height of 104 mm, and has a 2050 mm sliding table on roller guides. The machine has a scoring unit. The spindle moulder has a Ø 30 mm spindle with a usable length of 115 mm and 4 speeds (3500 / 6500 / 8000 / 10000 rpm), and the spindle tilts backwards. The worktables are made of cast iron. The saw and the spindle moulder have separate 5.5 kW motors, and the scoring unit a 0.55 kW motor. This machine is fitted with an extension frame with support arm, a crosscut fence with stops, a rip fence, aluminium spindle moulder fences, a spindle moulder guard with extraction connection and a control panel with digital display and position indicators on the adjusting handwheels. Condition: used machine in good working order. The year of manufacture, the location and the identification data of the machine, as well as any technical data not given here, are specified in the quotation.
