Weinig four side moulder

This used Weinig four side moulder planes and profiles solid wood on all four sides in a single pass, combining planing, straightening and profiling. It is built on a cast iron frame. It has 6 spindles: 1 bottom horizontal (5.5 kW), 2 right vertical and 3 left vertical (11 kW together), 4 top horizontal (7.5 kW), 5 top horizontal (5.5 kW) and 6 bottom horizontal (11 kW). The spindles have a diameter of Ø 40 mm and run at 8000 rpm. The working width is 230 mm and the working height 170 mm. The feed runs at 6–24 m/min, driven by a 4.0 kW motor via cardan shafts, with pneumatic pressure: 6 driven toothed top infeed rollers (one of them double), driven rubber-coated double outfeed rollers at the top and bottom, and a side pressure guide. The infeed table is 1700 mm long. The thickness and spindles 4 and 5 are adjusted by motor, and the body is raised by a 0.55 kW motor. The table has central lubrication and the machine has 6 extraction connections of Ø 140 mm. The total installed power is 50 kW; the overall dimensions are 4900 x 2400 x 2000 mm and the weight is 3500 kg. Condition: used machine in good working order. The year of manufacture, the location and the identification data of the machine, as well as any technical data not given here, are specified in the quotation.
