Sliding table saws
Robland sliding table saw
Used sliding table saw with 3200 mm cutting length, 1350 mm cutting width, Ø 400 mm blade tilting manually to 45° and a scoring unit with its own 0.75 kW motor.
Product code PM1049
About this machine
This used Robland sliding table saw is intended for sizing panels and for ripping and crosscutting in furniture workshops. It processes MDF, particleboard, plywood and solid wood.
The machine has a cutting length of 3200 mm and a cutting width of 1350 mm; the 3200 x 400 mm sliding table is made of anodised aluminium and runs on bearings. It takes a Ø 400 mm saw blade tilting manually 0°–45°, with a maximum cutting height of 125 mm, driven by a 5.5 kW motor. The scoring unit has its own 0.75 kW motor and a Ø 120 mm blade. The sawing unit has a cast iron structure.
This machine is fitted with a rip fence on a round guide bar, a crosscut fence on the extension frame and a suspended saw blade guard on a support arm. The machine weighs 1000 kg.
Condition: used machine in good working order, inspected and maintained. The year of manufacture, the location and the identification data of the machine, as well as any technical data not given here, are specified in the quotation.
Technical data
| Sliding table length | cutting length 3200 mm; sliding table 3200 x 400 mm |
|---|---|
| Cutting width at rip fence | 1350 mm |
| Main saw blade: maximum diameter / bore | Ø 400 mm |
| Cutting height at 90° / 45° | max. 125 mm |
| Main saw blade tilt | 0°–45°, manual |
| Main motor power | 5.5 kW |
| Scoring unit | yes |
| Scoring unit drive | 0.75 kW; scoring blade Ø 120 mm |
| Sliding table guidance and locking | anodised aluminium sliding table on bearings |
| Crosscut fence | on extension frame |
| Rip fence | on round guide bar |
| Saw blade guard | suspended guard on a support arm |
| Net weight | 1000 kg |
