Planers
Jaroma 2 side planer
Used 2 side planer with bottom and top cutterblocks, 400 mm working width, max. 170 mm working height, 6 / 12 m/min feed and 6 kW + 6 kW motor power.
Product code PM1058
About this machine
This used Jaroma 2 side planer planes solid wood on both faces in a single pass, with a bottom and a top cutterblock.
The working width is 400 mm and the maximum working height 170 mm. The maximum depth of cut is 6 mm on the bottom cutterblock and 5 mm on the top cutterblock. The feed runs at 6 / 12 m/min, the motor power is 6 kW + 6 kW and the machine weighs 1700 kg.
This machine is fitted with toothed feed rollers and rubber-coated rollers with chain drive, two dust extraction connections (top and bottom) and a control panel on a pedestal.
Condition: used machine in good working order. The year of manufacture, the location and the identification data of the machine, as well as any technical data not given here, are specified in the quotation.
Technical data
| Planer type | Double-sided planer |
|---|---|
| Maximum planing width | 400 mm |
| Maximum depth of cut, surfacing | 6 mm (bottom cutterblock) |
| Thicknessing capacity, min.–max. workpiece thickness | max. 170 mm |
| Maximum depth of cut, thicknessing | 5 mm (top cutterblock) |
| Feed speed | 6 / 12 m/min |
| Feed rollers | toothed feed rollers and rubber-coated rollers; chain drive |
| Main motor power | 6 kW + 6 kW |
| Dust extraction connections | 2 connections (top and bottom) |
| Machine weight | 1700 kg |
